2.3 Litre EcoBoost
The Ford Mustang is synonymous with a big V8 engine, so Ford’s decision to offer a 4 cylinder 2.3 option might have come as a shock. With a turbocharged 2.3 EcoBoost engine, this is not just a practical alternative to the V8, but now a contender thanks to Revo Software. Revo Stage 1 gave the 2.3 a new lease of life but Stage 2 is something else; it has serious grunt and a new sense of urgency. It doesn’t feel flat or underpowered anymore and really wants to pick up and go.
The increased midrange and top end is phenomenal, and makes it a much more rewarding car to drive; and It’s quick too, more responsive and has a much broader power band. With the additional power and torque, you can actually drive the car rather than just planting your foot and wishing there was more there. With the Stage 2 Pack, it’s now a fun, quick and very capable car, with more torque than the stock 5.0 V8.
An Enhanced Driving Experience
Revo offers some of the most substantial performance increases on the market, however, peak figures form part of a much bigger picture and are never the sole focus during development. Only Revo offers a perfect balance of performance, economy, longevity and safety. Development and testing of Revo performance software is done in a number of territories around the world, considering variations in atmospheric conditions such as altitude and temperature.
Software Features
Speed Limit Unlock
The top speed limit for this vehicle has been removed.
RPM Limit Increased
The RPM limit has been raised to 7000 RPM
Temperature Protection
Engine power is lowered under extreme temperatures.
Performance Data
All Data produced and taken from the same 2016 Ford Mustang 2.3 Ecoboost on our own in-house Dynapack hub dyno. The graphs show the stock vehicle with no software or hardware upgrades against the same vehicle with the full Revo Stage 2 Performance Pack upgrade, which includes software and hardware.
The graphs below show increase increases in both power and torque throughout the entire rev range, especially after 5200RPM, from a stock Mustang to the Revo Stage 2 Performance Pack
- Peak 104WHP Gain
- Peak 185NM Gain
- Max 270WHP Gain @ 6400RPM
- Max 300NM Gain @ 6400RPM
Mustang 2.3 EcoBoost - Power Dyno Graph (WHP)
Mustang 2.3 EcoBoost- Torque Dyno Graph (NM)
*All graph data produced using a 2016 Ford Mustang 2.3 EcoBoost with Standard Shell vpower Pump Fuel
Performance Times
Performance testing was carried out on a private track in the UK with an ambient temperature of 20ºC. The US Imported 2016 Performance Pack Ford Mustang 2.3 EcoBoost with a manual transmission. 20" wheels with road tyres, traction control off and 98RON Shell® vPower®.
| 0-60 mph | 0-100 mph | 30-70 mph | 30-130 mph | 100-200 kph | |
|---|---|---|---|---|---|
| Stock | 6.70 s | 17.04 s | 6.29 s | - | - |
| Stage 1 | 5.32 s | 12.90 s | 5.13 s | 20.57 s | 14.68 s |
| Stage 2 Package | 5.10 s | 11.74 s | 4.67 s | 18.08 s | 12.73 s |
Technical Data
- Speed Limit Raised to 186mph
- RPM Limit raised to 7000 RPM
- Shift indicator light at 6200 RPM
- Smoothed pedal response
- Temperature related protection
- Various fuel quality options
Temperature Protection
During testing it quickly came to light that the 2.3 EcoBoost engine suffers considerably with high temperatures. This not only affects the top-end power output of the engine but can also cause considerable damage. To prevent this from happening, our calibration team have incorporated Temperature Protection, an additional safety feature that limits engine power under extreme temperatures before damage to the engine.
How it Works
Revo Stage 2 tuning is developed to work with our stage 2 package hardware; even with the improved cooler temperatures from the Revo intercooler, we decided to leave the temperature protection in place. The additional Revo hardware manages to keep temperatures much lower than the stock parts, however, temperatures can still rise in high-temperature conditions (Rolling Road, High ambient temps, and prolonged vmax/track use) so for your piece of mind you know power will to reduced to protect your engine.
We have implemented additional safety features by reducing overall power as IAT's climb to undesirable levels.
- IAT over 45ºC; power is reduced by 5%
- IAT over 50ºC; power is reduced by 10%
- IAT over 60ºC, power is reduced by 15%
- IAT over 70ºC, power is reduced to around stage 1 level
Please note: IAT displayed on the dash clocks is not the true IAT being monitored by the ECU or the Temperature Protection feature.
The Revo Difference
OBD Port Install
Revo Software can be installed quickly and safely via the OBD Port without the need to open the ECU.
30 Day Guarantee
We know you'll love how Revo Software transforms your car. If you don't, we'll give you your money back.
Fuel Economy
Dependent on your driving style, this software will deliver like for like fuel economy in 'normal' driving conditions.
Required Hardware Upgrades
- Revo Air Intake System
- Revo Intercooler
- Revo Intercooler Pipe Upgrade
- Milltek Downpipe with Sports Cat
Recommended Hardware Upgrades
- Revo Big Brake Kit
Revo ECU Software is only available from one of over 400 Authorised Dealers worldwide. You can find your closest dealer by clicking here.
Please note that although we always aim to release ECU Software that covers as many ECU variants as possible, from time to time Revo Software may not be available for your specific vehicle. Your Revo Authorised Dealer can submit a code request direct to Revo HQ if this is the case, however this does not guarantee a file will be made available.
